BARNDOMINIUM
36X60'8''X10
1'480-SQFT OF PORCH'S
- LIVINGQUARTERS 2X6 STUDWALL FRAMING
- 2X6 EXTERIOR STUDS IN THE LIVINGQUARTERS
- FLAT BOTTOM COMMON TRUSSES
- MAIN ROOF PITCH 6:12
- EXTERIOR WALKIN DOORS
- 2 DOOR SLIDER DOORS
- VINYL LOW E WINDOWS
- 26 GAUGE METAL ON THE ROOF AND WALLS
- 26 GAUGE TRIM
- 6X6 CEDAR PORCH POSTS.
- 24X12 GABLE PORCH
-18" GABLE AND EAVE SOFFITED OVERHANG'S
- 2X4 INTERIOR WALLS.
- STUDS 16" OC-CONCRETE SLAB FOR HOUSE PORCH'S.
- VAPOR BARRIER UNDER ENCLOSED BUILDING SLAB
- 2 GARAGE DOOR'S. 1-18X8, 1- 12X12,
- 2- ELECTRIC OPENER'S.
HANGER
80X80X18
PRE ENGINEERED RED IRON METAL BUILDING
- 3'' INSULATION
- GALVALUME ROOF AND COLORED WALL METAL
- 80X80 SLAB 5 1/2'' THICK
- 18X18 FOOTINGS ON GABLE ENDWALLS
- 24X24 FOOTINGS ON SIDEWALL'S
- FOOTINGS TO HAVE 4 BARS #5 REBAR
- 2X6 PIERS UNDER 6 MAIN FRAME COLUMN FOOTINGS ON SIDEWALLS
- PROVIDING AND SETTING ANCHOR BOLTS IN WET CONCRETE
- 10 MIL VAPOR BARRIER UNDER BLDG SLAB
- 1/2'' REBAR 24''OC ON SLAB
HANGER
50X70X16 BOLTUP RED-IRON BUILDING
-ENGINEERED I BEAM FRAME
-26 GAUGE GALVALUME ROOF METAL R PANEL
-26 GAUGE COLORED R PANEL ON WALLS
-GUTTERING
-2:12 ROOF PITCH
-3'' VINYL BACK FIBERGLASS INSULATION ON THE ROOF AND WALLS
-2 WALKIN DOOR'S WITH DEADBOLT
-1- 12X8 FRAMED OPENING
-1- 45X13 FRAMED OPENING
-1- WHITE VINYL 3X4 WINDOW
-42X14 HIGHER POWER HANGAR DOOR FRAME AND OPENER
GARAGE/SHOP
50X75X16 RED-IRON BUILDING WITH A
12X75 LEAN2 ON 1 SIDE.
- 2- WALKIN DOOR'S (NO GLASS)
- 4- 12X12 GARAGE OVERHEAD DOORS
- 6 GAUGE GALVALUME PBR ROOF METAL
- 26 GAUGE PAINTED PBR WALL METAL
- 3'' FIBERGLASS INSULATION ON THE ROOF AND WALLS ON 50X75X16
-1:12 ROOF PITCH
- GUTTER AND DOWNSPOUTS
- METAL CEILING UNDER 12X75 LEAN2
GARAGE WITH LOFT
-2X6 STUDS 24" OC -TREATED
-2X6 BASE PLATE -DOUBLE
-2X6 TOP PLATE -2X4 ROOF AND WALL PURLINS 2'OC –
-2X6 ROOF TRUSSES 4'OC-2X4 ROOF AND WALL BRACING
-DOUBLE 2X12 DOOR AND WINDOW HEADERS
-4:12 ROOF PITCH
–HEAVY DUTY 26 GAUGE PAINTED AG-PANEL METAL ON THE ROOF & WALLS
-1 - 3' WALKIN DOOR
-6 - 3X3 WHITE VINYL SINGLE HUNG WINDOWS
-2" INSULATION ON WALLS AND ROOF
-1-14X14 RESIDENTAL, INSULATED GARAGE DOOR
-1-12X8 RESIDENTAL, INSULATED GARAGE DOOR
RED IRON BOLT UP BUILDING
40X80X14Â
-40X80X14 BUILDING FRAME
-7- 3X4 WINDOW'S
-1 WALKIN DOOR WITH 1/2 GLASS
-GUTTERING WITH DOWNSPOUTS
- 2- 12X12 COMMERCIAL INSULATED GARAGE DOORS
-26 GAUGE R PANELS ROOF AND WALL METAL
-COLOR ROOF AND WALL METAL
-24'' GABLE AND EAVE SOFFIT OVERHANG'S
-10X50 WRAP AROUND PORCH (PORCH HAS METAL CEILING)
POLEBARN GARAGE
40X60X12Â
- Pre-Engineered Wood Trusses (3/12 Pitch, 4' O/C)Â
-5X5 TREATED EAVE POSTS (8' O/C)Â
- 5X5 TREATED EAVE POSTS (8' O/C)Â
-2 x 6 Treated Skirt Boards (1 Row)Â
- 2 x 4 Wall Girts (24" O/C)Â
- Roof Purlins (24" O/C)Â
- 2 x 10 Double Top Girt Truss Carrier
- 26Gauge AG Panel Rib Steel Siding -
- 26Gauge AG Panel Rib Steel RoofÂ
- 3- 16X10 DOORÂ
- 1- 3' Flush Entry Door.Â
POLEBARN BUILDING
30X50X12 WITH A 10X50 LEAN2 ON 1 SIDE
- LEAN2 1/2(25') ENCLOSED AND 1/2(25') OPEN PORCH STYLE
- 5X5 TREATED POSTS 8'OCÂ
- 2X4 ROOF AND WALL PURLINS 2'OCÂ
- 2X6 ROOF TRUSSES 4'OCÂ
- 2X4 ROOF AND WALL BRACINGÂ
- 3:12 ROOF PITCHÂ
- HEAVY DUTY 26 GAUGE AG-PANEL METAL ON THE ROOF AND WALLS
- 1- WALKIN DOOR WITH 1/2 GLASS GRIDSÂ
- 1 WALKIN DOOR WITHOUT GLASSÂ
- 1- 3X4 VINYL WINDOW
- 1- 10X10 GARAGE DOOR AND 1- 8X8 GARAGE DOOR
LEANTO
16X60X10Â
LEANTO OFF SIDEWALL OF EXISTING BUILDINGÂ
-Â 5X5 TREATED POSTS 8' O.C ON SIDEWALLÂ
- 26 GAUGE AG PANEL METAL ON ROOF AND WALLSÂ
- 2X4 GIRTS AND ROOF PURLINS 2' O.CÂ
- 2X12 RAFTERS 4' O.C ON ROOFÂ
- DOUBLE 2X10 HEADERS AND GARAGE DOOR HEADERSÂ
- 1 -10X10 DOOR OPENINGÂ
- 2Â 10X7 DOOR OPENING (OPENINGS ONLY)Â
- 1 6X60 CONCRETE SLAB, 4.5'' THICK FOR, 1/2'' REBAR 24''OC
- 1 RESIDENTIAL INSULATED GARAGE DOOR
- 1 10X10 GARAGE DOOR WHITEÂ
